Home Product Presentation BY-XM6-K2

• Ideal for two-person vlog,
    YouTube video, live streaming,interview, recording, etc.
 • Compatible with DSLR, mirrorless
    camera, smartphone,and computer.
 • 2.4GHz wireless signal transmission technology.
 •  Hi-Fi and low-noise audio processing and delivering system.
 • Built with easy-to-use, vivid, and informative OLED display.
 • Built-in omnidirectional microphone and a lavalier
   microphone on transmitter.
 • Headphone output jack on receiver for real-time monitoring.
 • Stereo and mono outputs are available and switchable
   on receiver.
 • Built-in Li-ion batteries for 7h use on transmitter and 6.5h
   use on receiver.
 • Up to 100m (328ft) operation range without obstacles.
 • Equipped with a portable charging case
 • Double the working hours

Product Introduction

The BOYA BY-XM6-K2, a 2.4GHz adaptive frequency hopping wireless microphone system, consists of two transmitter, one receiver, as well as a charging case. It’s a perfect sound capturing, meanwhile delivering solution for two-person vlog, YouTube video, live streaming, interview, recording, etc. Advanced Technology for Stable Signal Transmission The BY-XM6 K2 adopts advanced Adaptive Frequency Hopping (AFH) wireless signal transmission technology, which can make the microphone avoid the disturbed hop frequency parts automatically to realize stable signal transmission in the range of up to 100m (328ft), without obstacle.

Overview

Parameter

Download

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

View All

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

boya xm6 wireless microphone

Put it all away

Transmitter

Transmission Type

2.4GHz Digital Frequency

Modulation

GFSK

Operating Range (without obstacle)

Up to 328ft (100m)

RF Output Power

＜10mW

Polar Pattern

Omnidirectional

Frequency Response

50Hz-18KHz

Maximum SPL

Built-in Microphone: 120dB SPL

Lavalier Microphone

110dB SPL

Sensitivity

Built-in Microphone:-39dB / Lavalier Microphone:-39dB

SNR

> 84dB

Power Requirements

Built-in Li-ion Battery or USB-C DC 5V or Charging Contact

Built-in Battery Life

Approx. 7 hours

Antenna

PIFA Antenna

Audio Inputs

3.5mm TRS MIC/LINE IN Jack or Built-in Microphone

Weight

Approx. 32g(1.13oz)

Dimensions

62.1×31.6×16.5mm

Operating Temperature

–10℃ to 50℃

Storage Temperature

–20℃ to +55℃

Receiver

Transmission Type

2.4GHz Digital Frequency

Modulation

GFSK

Operating Range (without obstacle)

Up to 328ft (100m)

Audio Output Connector

3.5mm Headphone Jack / 3.5mm TRS Output Jack

Audio Output Level

–60 dBV to -20dBV

Power Requirements

Built-in Li-ion Battery or USB-C DC 5V or Charging Contact

Built-in Battery Life

Approx. 6.5 hours

Antenna

PIFA Antenna

Weight

Approx. 32g(1.13oz)

Dimensions

62.1×31.6×16.5mm

Operating Temperature

–10℃ to 50℃

Storage Temperature

–20℃ to +55℃

Charging case

Power Requirements

USB-C DC 5V/1.5A

Power Capacity

3000mAh

Box's Charging Time

4.5 hours

Weight

200g

Dimensions

125x96.8×35.6mm

Operating Temperature

-10℃ to 50℃

Storage Temperature

-20℃ to +55℃

Packing List

BY-XM6 TX Transmitter×2

BY-XM6 RX Receiver×1

USB-C Charging Cable×3

Lavalier Microphone×2

Mic Clip for Lavalier Microphone×2

Foam Windscreen for Lavalier Microphone×2

Fur Windshield for Built-in Microphone×2

3.5mm TRS to TRS Output Cable for Cameras×1

3.5mm TRS to TRRS Output Cable for Smartphones×1

Charging Case×1

View All

Transmitter

Transmission Type

2.4GHz Digital Frequency

Modulation

GFSK

Operating Range (without obstacle)

Up to 328ft (100m)

RF Output Power

＜10mW

Polar Pattern

Omnidirectional

Frequency Response

50Hz-18KHz

Maximum SPL

Built-in Microphone: 120dB SPL

Lavalier Microphone

110dB SPL

Sensitivity

Built-in Microphone:-39dB / Lavalier Microphone:-39dB

SNR

> 84dB

Power Requirements

Built-in Li-ion Battery or USB-C DC 5V or Charging Contact

Built-in Battery Life

Approx. 7 hours

Antenna

PIFA Antenna

Audio Inputs

3.5mm TRS MIC/LINE IN Jack or Built-in Microphone

Weight

Approx. 32g(1.13oz)

Dimensions

62.1×31.6×16.5mm

Operating Temperature

–10℃ to 50℃

Storage Temperature

–20℃ to +55℃

Receiver

Transmission Type

2.4GHz Digital Frequency

Modulation

GFSK

Operating Range (without obstacle)

Up to 328ft (100m)

Audio Output Connector

3.5mm Headphone Jack / 3.5mm TRS Output Jack

Audio Output Level

–60 dBV to -20dBV

Power Requirements

Built-in Li-ion Battery or USB-C DC 5V or Charging Contact

Built-in Battery Life

Approx. 6.5 hours

Antenna

PIFA Antenna

Weight

Approx. 32g(1.13oz)

Dimensions

62.1×31.6×16.5mm

Operating Temperature

–10℃ to 50℃

Storage Temperature

–20℃ to +55℃

Charging case

Power Requirements

USB-C DC 5V/1.5A

Power Capacity

3000mAh

Box's Charging Time

4.5 hours

Weight

200g

Dimensions

125x96.8×35.6mm

Operating Temperature

-10℃ to 50℃

Storage Temperature

-20℃ to +55℃

Packing List

BY-XM6 TX Transmitter×2

BY-XM6 RX Receiver×1

USB-C Charging Cable×3

Lavalier Microphone×2

Mic Clip for Lavalier Microphone×2

Foam Windscreen for Lavalier Microphone×2

Fur Windshield for Built-in Microphone×2

3.5mm TRS to TRS Output Cable for Cameras×1

3.5mm TRS to TRRS Output Cable for Smartphones×1

Charging Case×1
